3.2km Measurement Range Ground Based Radar Surveillance All Weather Monitoring

Name: 32km Measurement Range Ground Based Radar Surveillance All Weather Monitoring
Brand: Lei Tan
Price: 1 USD

Quality 3.2km Measurement Range Ground Based Radar Surveillance All Weather Monitoring for sale

Brand Name : Lei Tan

Model Number : LTSR115-0500C

MOQ : 1

Payment Terms : ,L/C,D/A,D/P,T/T,Western Union,MoneyGram

Measurement Range : 3.2km

Effective Detection Range : 100m～1.5km(Pedestrian) 100m～3.0km(Sedan)

Intelligent filtering of false alarms : Intelligent recognition of human and vehicle targets, automatic filtering of false alarm targets such as birds and trees

Customizable : Products can be customized according to different needs

Contact Now

Advanced Ground Security Radar With Multi-Sensor Fusion For Target Tracking
I. Product Description
The Ground Security Radar is a high-tech security device specifically designed for critical areas such as borders, perimeters, checkpoints, and  bases. It is capable of real-time detection and tracking of targets such as pedestrians and vehicles, providing accurate information on direction, distance, and speed. Combined with optoelectronic technology, the radar can automatically detect and identify suspicious intruding targets, and achieve automatic tracking and surveillance, offering comprehensive security protection.
II. Product Features
All-Weather Monitoring: The radar can operate stably even in harsh weather conditions, ensuring uninterrupted monitoring.
Powerful Tracking Capability: The radar can continuously and stably track fast-moving targets, ensuring they remain within the surveillance range.
Wide-Area Coverage: By forming an array with multiple radars, seamless coverage of large areas can be achieved, meeting the complex requirements of borders and perimeters.
Intelligent Identification and Filtering: The radar can accurately distinguish between pedestrians and vehicles, and automatically filter out false alarms from birds, trees, etc., reducing false alarms.
Flexible Customization: The radar can be customized according to user requirements to meet the special needs of different scenarios.
III. Product Functions
Remote Management: Supports remote on/off control and real-time status reporting of the device, allowing users to manage the radar equipment via the network.
Multi-Target Tracking and Information Output: Capable of tracking multiple targets simultaneously and outputting real-time information on their distance, speed, and angle.
Intelligent Linkage: The radar can be linked with a pan-tilt unit to achieve target-following tracking and evidence capture, supporting various tracking modes.
Fault Alarm and Self-Inspection: Features real-time monitoring of working status, fault alarms, and offline alarms for the device, as well as online self-inspection to ensure stable operation.
IV. Competitive Advantages
Advanced Technology: The radar employs advanced phased array technology, enabling rapid scanning and data processing capabilities, and can more accurately obtain key information such as target direction, distance, and speed.
Stable Operation: Equipped with a high-performance power adapter, the radar can operate stably in various environments, unaffected by power fluctuations.
Multi-Target Tracking: The radar can automatically track multiple targets, capturing them accurately regardless of their movements, providing reliable security protection.

3.2km Measurement Range Ground Based Radar Surveillance All Weather Monitoring

V. Parameters

Operating Frequency Band	C-band
Measurement Range	3.2km
Effective Detection Range	100m～1.5km(Pedestrian) 100m～3.0km(Sedan)
Azimuth Coverage	≥90°
Elevation Angle Coverage	≥18°
Detection Speed	1.8km/h～108km/h
Azimuth Accuracy	≤1.0°
Range Accuracy	≤10m
Data Rate	≥2Hz
Data Interface	RJ45/1 x 100Mbps Ethernet
Power Input	Power consumption: ≤55W Input voltage: AC 220V~240V
Operating Temperature	-40℃～+55℃
Weight	≤5.5kg

3.2km Measurement Range Ground Based Radar Surveillance All Weather Monitoring

Product Tags:

3.2km Range Ground Based Radar Surveillance

All Weather Ground Based Radar Surveillance

3.2km Range ground security radar

3.2km Measurement Range Ground Based Radar Surveillance All Weather Monitoring Images
